RS232 TTL UART 5V USB Conversion Line USB TO 110 Terminal 4P Console cable for Motorcycle

RS232 TTL UART 5V USB Conversion Line USB TO 110 Terminal 4P Console cable for Motorcycle

Short Description:

RS232 TTL UART 5V


Product Details

Product Tags

Quick Details

  • Model Number:

  • ACE-FTRS3245

  • Type:

  • Active Optical Cables, TTL Serial

  • Place of Origin:

  • Guangdong, China

  • Brand Name:

  • ACE-Clouds

  • Number of Conductors:

  • 4

  • Certification:

  • RoHS/REACH

  • Length:

  • 1.8m(6FT), Custom-made

  • Color:

  • Black, Custom-made

  • Voltage:

  • 5V

  • Conductor Material:

  • Oxygen-free copper

  • Chipset:

  • FTDI RS232RL

  • Jacket:

  • PVC, TPE, Custom-made

  • Packing:

  • Polybag or Giftbox, Blister Packing

  • Function:

  • Adjust speed of motorcycle, Car etc

  • Selling Units:

  • Single item

  • Single package size:

  • 12X12X3 cm

  • Single gross weight:

  • 0.100 kg

  • Package Type:

  • PE Bag

  • Picture Example:


  • Lead Time:

  • Quantity(Pieces)1 - 200201 - 10001001 - 2000>2000
    Est. Time(days)153242To be negotiated

    RS232 TTL UART 5V USB Conversion Line USB TO 110 Terminal 4P Console cable for Motorcycle

    TIP:

    1. TTL is available in 3.3V and 5V;
    If you need different parameters, please contact us.



    This cable is mainly used for debugging the motor speed of industrial equipment such as motorcycles and automobiles. We can also customize the serial cable of various industrial equipment according to requirements. If you need, you can contact us at any time.



    1) USB to TTL converter cable with a 4-pin header connector incorporates FTDI’s FT232RL chip handling all signaling and protocols.
    2) The cables interface provides a simple and fast way to the connector to devices with TTL level serial interfaces.
    3) The converter cable’s electronics are molded into the USB end of the cable providing baud rate speeds from 300 baud to 5M baud and 5 volts power.
    4) Incorporates FTDI FT232RL chipset
    5) 6ft. long cable length
    6) USB 2.0 compliant enabling 300 baud up to 3M baud
    7) 110 4Pin header connector providing 5 volts of power



    PRODUCT SPECIFICATION

    Length
    1.8m(6ft),Custom-made
    Color
    Black, Custom-made
    Conductor
    Bare Copper
    Chip
    FTDI RS232
    Core
    4 Cores
    Conversion Type
    USB to 5V Converter
    Type
    TTL
    Jacket
    PVC, TPE Optional
    Outer Diameter
    4.0mm
    Connector A
    USB2.0 Male
    Connector B
    110 4Pin
    Certificate
    ROHS/CE/FCC
